Neodymium Cup Magnets

NEO POT 500The magnets (NdFeB) are embedded in a steel cup-plastic injected, Ni plated. The steel pot increases the pull force of the magnet on direct contact with a thick iron surface. If you need assistance with your requirements, please contact us.


  • pot C sink 150

    PMN-CS-16

    D – 0.63″

    H – 0.2″

    d – 0.14″               Ni  Plated

    d1 – 0.26″            Pull force 11 lb

    Clear
  • pot C sink 150

    PMN-CS-20

    D – 0.787″

    H – 0.276″

    d – 0.177″             Ni  Plated

    d1 – 0.335″         Pull force 14 lb

    Clear
  • pot C sink 150

    PMN-CS-25

    D – 0.984″

    H – 0.315″

    d – 0.217″             Ni  Plated

    d1 – 0.41″         Pull force 31 lb

    Clear
  • PMN-150S

    PMN – 150S

    D – 1.5″

    H – 0.35″                  Ni Plated

    h – 0.78″                   Pull force 120 lb

    d- 5/16-18 threaded stud

    Clear
  • N-POT50

    PMN-BS-50SS

    Neodymium (NdFeB) pot magnet. The magnet is covered with stainless steel case

    D – 2.035″

    H – 0.29″

    d – 0.19″               CuNiCr Coating

    d1 – 0.56″            Pull force 85 lb

    Clear
  • BS-20

    PMN-BS-20

    D – 0.79″

    H – 0.27″

    d – 0.17″               Ni Plated

    d1 – 0.31″            Pull force 13 lb

    Clear
  • BS-20

    PMN-BS-25

    D – 0.99″

    H – 0.31″

    d – 0.21″                   Ni Plated

    d1 -0.35″                 Pull force 30 lb

    Clear
  • BS-20

    PMN-BS-32

    D – 1.26″

    H – 0.31″

    d – 0.21″                  Ni Plated

    d1 – 0.35″               Pull force 50.5 lb

    Clear
  • BS-20

    PMN-BS-36

    D – 1.42″

    H – 0.35″

    d – 0.25″                  Ni Plated

    d1 – 0.43″               Pull force 63 lb

    Clear
  • BS-20

    PMN-BS-42

    D – 1.65″

    H – 0.35″

    d – 0.25″                    Ni Plated

    d1 – 0.43″                 Pull force 70.5 lb

    Clear
