Rare Earth Magnets & Ceramic Magnets
Magnets With CSK Hole
We supply any standard, custom, and OEM magnets of various shape and size from the N52, 48M, 45H, 42SH, 35UH and 33EH series at the lowest price within 10-15 days. The following coatings are available: Uncoated, Ni Cu Ni, Zinc, Gold, Silver, Epoxy, Phosphatised, Cr, Ni black Ni, and Cu. Fast delivery on Non stock Neodymium Magnets. Best Quality & Lowest Price. Non stock magnets / Custom magnets / OEM Magnets / Micro Magnets / Samples of Custom Magnets / Samples of any grade and size on non stock magnets. If you need assistance with your requirements, please contact us.
Dimensions: DIAMETER x THICKNESS, Tolerance: – / + 0.005″ (0.1mm)
-
OD3/8″ x 1/8″ thick with #4 countersunk hole
OD9.525 x 3.175mm thick with #4 countersunk hole
Material: NdFeB Grade: N42
Coating: Ni (NiCuNi) Pull Force: 3.8 lb
Magnetized: Axially (countersunk on North “N” side)
Br max: 13200 Gauss
Surface Field: 1995 Gauss
Max. Oper. Temperature : 80 C
-
OD1/2″ x 1/8″ thick with #4 countersunk hole (N)
OD12.7 x 3.175mm thick with #4 countersunk hole
Material: NdFeB Grade: N42
Coating: Ni (NiCuNi) Pull Force: 6 lb
Magnetized: Axially (countersunk on North “N” side)
Br max: 13200 Gauss
Surface Field: 2460 Gauss
Max. Oper. Temperature : 80 C
-
OD1/2″ x 1/8″ thick with #4 countersunk hole (S)
OD12.7 x 3.175mm thick with #4 countersunk hole
Material: NdFeB Grade: N42
Coating: Ni (NiCuNi) Pull Force: 6 lb
Magnetized: Axially (countersunk on South “S” side)
Br max: 13200 Gauss
Surface Field: 2460 Gauss
Max. Oper. Temperature : 80 C
-
OD5/8″ x 1/8″ thick with #6 countersunk hole (N)
OD15.875 x 3.175mm thick with #6 countersunk hole
Material: NdFeB Grade: N42
Coating: Ni (NiCuNi) Pull Force: 7.3 lb
Magnetized: Axially (countersunk on North “N” side)
Br max: 13200 Gauss
Surface Field: 3030 Gauss
Max. Oper. Temperature : 80 C
-
OD5/8″ x 1/8″ thick with #6 countersunk hole (S)
OD15.875 x 3.175mm thick with #6 countersunk hole
Material: NdFeB Grade: N42
Coating: Ni (NiCuNi) Pull Force: 7.3 lb
Magnetized: Axially (countersunk on South “S” side)
Br max: 13200 Gauss
Surface Field: 3030 Gauss
Max. Oper. Temperature : 80 C
-
OD3/4″ x 1/8″ thick with #8 countersunk hole (N)
OD19.05 x 3.175mm thick with #8 countersunk hole
Material: NdFeB Grade: N42
Coating: Ni (NiCuNi) Pull Force: 9.2 lb
Magnetized: Axially (countersunk on North “N” side)
Br max: 13200 Gauss
Surface Field: 2585 Gauss
Max. Oper. Temperature : 80 C
-
OD3/4″ x 1/8″ thick with #8 countersunk hole (S)
OD19.05 x 3.175mm thick with #8 countersunk hole
Material: NdFeB Grade: N42
Coating: Ni (NiCuNi) Pull Force: 9.2 lb
Magnetized: Axially (countersunk on South “S” side)
Br max: 13200 Gauss
Surface Field: 2585 Gauss
Max. Oper. Temperature : 80 C
-
OD7/8″ x 1/8″ thick with #8 countersunk hole (N)
OD22.23 x 3.175mm thick with #8 countersunk hole
Material: NdFeB Grade: N42
Coating: Ni (NiCuNi) Pull Force: 10.6 lb
Magnetized: Axially (countersunk on North “N” side)
Br max: 13200 Gauss
Surface Field: 2850 Gauss
Max. Oper. Temperature : 80 C
-
OD7/8″ x 1/8″ thick with #8 countersunk hole (S)
OD22.23 x 3.175mm thick with #8 countersunk hole
Material: NdFeB Grade: N42
Coating: Ni (NiCuNi) Pull Force: 10.6 lb
Magnetized: Axially (countersunk on South “S” side)
Br max: 13200 Gauss
Surface Field: 2850 Gauss
Max. Oper. Temperature : 80 C
-
OD1″ x 3/16″ thick with #10 countersunk hole
OD25.4 x 4.76mm thick with #10 countersunk hole
Material: NdFeB Grade: N42
Coating: Ni (NiCuNi) Pull Force: 21.9 lb
Magnetized: Axially
Br max: 13200 Gauss
Surface Field: 3440 Gauss
Max. Oper. Temperature : 80 C
-
OD1″ x 1/4″ thick with #8 double side countersunk hole
OD25.4 x 6.35mm thick with #8 countersunk on both sides of the hole
Material: NdFeB Grade: N42
Coating: Ni (NiCuNi) Pull Force: 25.6 lb
Magnetized: Axially
Br max: 13200 Gauss
Surface Field: 2950 Gauss
Max. Oper. Temperature : 80 C
-
OD1-1/2″ x 3/8″ thick with #10 double side countersunk hole
OD38.1 x 9.53mm thick with #10 countersunk on both sides of the hole
Material: NdFeB Grade: N52
Coating: Ni (NiCuNi) Pull Force: 70.9 lb
Magnetized: Axially
Br max: 14800 Gauss
Surface Field: 3735 Gauss
Max. Oper. Temperature : 60 C
-
1/2″ x 1/2″ x 1/4″ thick with 0.34″ x 0.20″ 90 degree countersunk hole
12.7 x 12.7 x 6.35 mm thick with 8.64 x 5.08mm 90 degree countersunk hole
Material: NdFeB Grade: N52
Coating: Ni (NiCuNi) Pull Force: 13 lb
Magnetized: Through Thickness
Br max: 14800 Gauss
Surface Field: 2135 Gauss
Max. Oper. Temperature : 60 C
-
0.787″ x 0.787″ x 0.394″ thick with 0.34″ x 0.20″ 90 degree countersunk hole
20 x 20 x 10mm thick with 8.64 x 5.08mm 90 degree countersunk hole
Material: NdFeB Grade: N52
Coating: Ni (NiCuNi) Pull Force: 26 lb
Magnetized: Through Thickness
Br max: 14800 Gauss
Surface Field: 2300 Gauss
Max. Oper. Temperature : 60 C
-
1″ x 1/2″ x 1/8″ thick with two 0.310″ x 0.16″, 90 degree countersunk holes
25.4 x 12.7 x 3.175mm thick with two 7.87 x 4.06mm, 90 degree countersunk holes
Material: NdFeB Grade: N52
Coating: Ni (NiCuNi) Pull Force: 12.8 lb
Magnetized: Through Thickness
Br max: 14800 Gauss
Max. Oper. Temperature : 60 C
-
1″ x 1/2″ x 1/4″ thick with two #4 countersunk holes
25.4 x 12.7 x 6.35mm thick with two #4 countersunk holes
Material: NdFeB Grade: N42
Coating: Ni (NiCuNi) Pull Force: 20 lb
Magnetized: Through Thickness
Br max: 13200 Gauss
Max. Oper. Temperature : 80 C
